CLOSE OUT SALE

ADU.24 -  1u Dual 24 way Active Antenna Divider with BNC Connectors & 48 BNC to BNC patch Cables
1u form factor - about 8" deep + connectors
    • Fitted with 2x BNC rear panel connectors to accept BNC terminated antennas or cables to remote antennas.
    • Fitted with 48 BNC connectors - 24 "A" plus 24 "B" (with 12v DC power for Sennheisers)
    • Comes with 48x 50ohm BNC-BNC cables - select your length from 100mm, 150mm, 200mm, 300mm (mixed lengths ok - leave us a note - we used 12 of each length when mounting the ADU.24 with 12 above and 12 below for an incredibly neat finish)
    • Direct AC power in with a pair of 10A internal 12v power supplies capable of powering 24 Sennehsier ew100, ew300, ew500 via BNC or 24 Shure SLX, QLXD or ULXD via 1 power loom.
    • Use with any wireless systems that uses BNC or SMA* antenna connectors
*SMA - we have BNC to SMA cables in lengths from 4" to 16"
Bodymics is a US based Manufacturer and
Distributor of Wireless Microphones Accessories
  • Frequency Range:     470MHz-900MHz
  • All fitted in a 19" x 1.75" rack mount case
  • Needs between 10" and 12" of mounting depth (including connectors)
  • 1 year Warranty - Faulty Materials and Workmanship

Retail RFdWA AADA

Creative Audio

(C5) CA ADU.24 Antenna Active Distribution - Wireless Mic 1u Dual 24 way - BNC with power for 24 units

SKU ADU.24-SE
$ 2,799.00
$ 999.00

CLOSE OUT SALE

ADU.24 -  1u Dual 24 way Active Antenna Divider with BNC Connectors & 48 BNC to BNC patch Cables
1u form factor - about 8" deep + connectors
    • Fitted with 2x BNC rear panel connectors to accept BNC terminated antennas or cables to remote antennas.
    • Fitted with 48 BNC connectors - 24 "A" plus 24 "B" (with 12v DC power for Sennheisers)
    • Comes with 48x 50ohm BNC-BNC cables - select your length from 100mm, 150mm, 200mm, 300mm (mixed lengths ok - leave us a note - we used 12 of each length when mounting the ADU.24 with 12 above and 12 below for an incredibly neat finish)
    • Direct AC power in with a pair of 10A internal 12v power supplies capable of powering 24 Sennehsier ew100, ew300, ew500 via BNC or 24 Shure SLX, QLXD or ULXD via 1 power loom.
    • Use with any wireless systems that uses BNC or SMA* antenna connectors
*SMA - we have BNC to SMA cables in lengths from 4" to 16"
Bodymics is a US based Manufacturer and
Distributor of Wireless Microphones Accessories
  • Frequency Range:     470MHz-900MHz
  • All fitted in a 19" x 1.75" rack mount case
  • Needs between 10" and 12" of mounting depth (including connectors)
  • 1 year Warranty - Faulty Materials and Workmanship

Retail RFdWA AADA
$ 2,799.00
$ 999.00
Cable Set:

Frequently Bought Together

Total price $ 32,545.00

Product Description

CLOSE OUT SALE

ADU.24 -  1u Dual 24 way Active Antenna Divider with BNC Connectors & 48 BNC to BNC patch Cables
1u form factor - about 8" deep + connectors
    • Fitted with 2x BNC rear panel connectors to accept BNC terminated antennas or cables to remote antennas.
    • Fitted with 48 BNC connectors - 24 "A" plus 24 "B" (with 12v DC power for Sennheisers)
    • Comes with 48x 50ohm BNC-BNC cables - select your length from 100mm, 150mm, 200mm, 300mm (mixed lengths ok - leave us a note - we used 12 of each length when mounting the ADU.24 with 12 above and 12 below for an incredibly neat finish)
    • Direct AC power in with a pair of 10A internal 12v power supplies capable of powering 24 Sennehsier ew100, ew300, ew500 via BNC or 24 Shure SLX, QLXD or ULXD via 1 power loom.
    • Use with any wireless systems that uses BNC or SMA* antenna connectors
*SMA - we have BNC to SMA cables in lengths from 4" to 16"
Bodymics is a US based Manufacturer and
Distributor of Wireless Microphones Accessories
  • Frequency Range:     470MHz-900MHz
  • All fitted in a 19" x 1.75" rack mount case
  • Needs between 10" and 12" of mounting depth (including connectors)
  • 1 year Warranty - Faulty Materials and Workmanship

Retail RFdWA AADA
